需求

GrayLog每天每周产生的安全告警数量较多，这些产生的告警都通过PrometheusAlert推送到钉钉webhook告警机器人

想对这些告警做一些汇总统计，报表分析

(图片点击放大查看)

解决思路：

由于GrayLog Web界面上的告警界面无汇总统计的功能，只能寻找其他解决思路，查询prometheusalert是否有统计功能但搜索过PrometheusAlert的相关功能，与需求不太吻合。

突发奇想，看能否从PrometheusAlert.log的日志进行下手

通过查看PrometheusAlert.log的一些规律，最终确定的解决方法

包含value.go的这一行就是所需要的告警日志

2022/10/14 14:15:15.735 [D] [value.go:476]  [1665728115735353131] {"event_definition_id":"62d40b5bfbbe0a2fd4faf65d","event_definition_type":"aggregation-v1","event_definition_title":"堡垒机绕过提醒","event_definition_description":"安全助手检测到绕过堡垒机直接登陆服务器行为","job_definition_id":"62d3ff2bfbbe0a2fd4fadd35","job_trigger_id":"6348fe7213d8e16f7fe61732","event":{"id":"01GFAJ3W0SZSGJNTK01QKMRQXB","event_definition_type":"aggregation-v1","event_definition_id":"62d40b5bfbbe0a2fd4faf65d","origin_context":"urn:graylog:message:es:linuxserver_23:e6490781-4b86-11ed-aea0-005056b6acae","timestamp":"2022-10-14T06:10:46.428Z","timestamp_processing":"2022-10-14T06:15:14.713Z","timerange_start":null,"timerange_end":null,"streams":[],"source_streams":["62d3eed0fbbe0a2fd4facacd"],"message":"堡垒机绕过提醒","source":"localhost","key_tuple":[],"key":"","priority":2,"alert":true,"fields":{},"group_by_fields":{}},"backlog":[{"index":"linuxserver_23","message":"Accepted password for root from 192.168.29.41 port 60382 ssh2","timestamp":"2022-10-14T06:10:46.428Z","fields":{"process_id":"3194","gl2_accounted_message_size":292,"application_name":"sshd","level":6,"gl2_remote_ip":"172.16.252.134","gl2_remote_port":64781,"facility_num":10,"Linux_server_ssh_login_ip":"192.168.29.41","gl2_message_id":"01GFAHV3ZRYPS0G895J23348A6","gl2_source_node":"d20e3549-da0a-4ae9-af4a-d352e1c3deb5","gl2_source_input":"62d3ec98fbbe0a2fd4fac816","facility":"security/authorization"},"id":"e6490781-4b86-11ed-aea0-005056b6acae","source":"ec-server-test-172-16-252-134","stream_ids":["62d3eed0fbbe0a2fd4facacd"]}]}

1、使用rsyslog服务来读取prometheusalert.log日志文件

[root@centos ~]# cd /etc/rsyslog.d/
[root@centos rsyslog.d]# vi prometheusalert_read.conf
[root@centos rsyslog.d]# cat prometheusalert_read.conf
module(load="imfile" PollingInterval="1")
# Input for FILE1
#wildcard is allowed at file level only
input(
      type="imfile"
      tag="Alertlog"
      ruleset="filelog"
      Facility="local0"
      Severity="info"
      PersistStateInterval="1"
      reopenOnTruncate="on"
      freshStartTail="on"
      file="/opt/PrometheusAlert/logs/prometheusalertcenter.log"
)

# Define a template for file events
template(name="GraylogFormatFilelog" type="string" string="%msg%n")

#Replace the Target and Port values with your GrayLogServer IP address and port.
ruleset(name="filelog") {
   action(
        type="omfwd"
        protocol="udp"
        target="192.168.31.170"
        port="1524"
        template="GraylogFormatFilelog"
        queue.type="LinkedList"
        queue.filename="fileq1"
        queue.saveonshutdown="on"
        action.resumeRetryCount="-1"
   ) stop
}

[root@centos rsyslog.d]# systemctl restart rsyslog

(图片点击放大查看)

2、创建Index,Input和Stream

[root@centos ~]# firewall-cmd --permanent --zone=public --add-port=1524/udp
success
[root@centos ~]# firewall-cmd --reload
success
[root@centos ~]# systemctl restart rsyslog.service
[root@centos ~]#

(图片点击放大查看)

3、字段提取

在日志搜索栏中搜索告警日志后进行提取器配置，提取所需的字段

(图片点击放大查看)

例如这里使用正则表达式进行字段的提取

(图片点击放大查看)

以下为导出的提取器语法配置文件

{
  "extractors": [
    {
      "title": "alert_json_message",
      "extractor_type": "regex",
      "converters": [],
      "order": 1,
      "cursor_strategy": "copy",
      "source_field": "message",
      "target_field": "alert_json_message",
      "extractor_config": {
        "regex_value": "^.*\[[0-9]{19}\](.+)$"
      },
      "condition_type": "string",
      "condition_value": "value.go"
    },
    {
      "title": "json_extractor",
      "extractor_type": "json",
      "converters": [],
      "order": 2,
      "cursor_strategy": "copy",
      "source_field": "alert_json_message",
      "target_field": "",
      "extractor_config": {
        "list_separator": ", ",
        "kv_separator": "=",
        "key_prefix": "",
        "key_separator": "_",
        "replace_key_whitespace": false,
        "key_whitespace_replacement": "_"
      },
      "condition_type": "none",
      "condition_value": ""
    },
    {
      "title": "field_cut",
      "extractor_type": "copy_input",
      "converters": [
        {
          "type": "tokenizer",
          "config": {}
        }
      ],
      "order": 3,
      "cursor_strategy": "copy",
      "source_field": "backlog",
      "target_field": "backlog_detail",
      "extractor_config": {},
      "condition_type": "none",
      "condition_value": ""
    },
    {
      "title": "level_replace",
      "extractor_type": "regex_replace",
      "converters": [],
      "order": 0,
      "cursor_strategy": "copy",
      "source_field": "message",
      "target_field": "message",
      "extractor_config": {
        "replacement": ""alertlevel"",
        "regex": ""level""
      },
      "condition_type": "none",
      "condition_value": ""
    },
    {
      "title": "facility_num_replace",
      "extractor_type": "regex_replace",
      "converters": [],
      "order": 0,
      "cursor_strategy": "copy",
      "source_field": "message",
      "target_field": "message",
      "extractor_config": {
        "replacement": ""alert_facility_num"",
        "regex": ""facility_num""
      },
      "condition_type": "none",
      "condition_value": ""
    }
  ],
  "version": "4.2.10"
}
